MSC-629S62-25

Description: TURBINE OIL ELEMENTS

Specifications:
  • Performance Data
    Micron Rating: 15.00
    Beta Rating 75
    Collapse Pressure Rating 75 PSID
    Maximum Temperature 225 F
    Direction of Flow
    Recommended Changeout Differential Pressure 25
  • Dimensional Data
    (A) Outer Diameter, Top 6.00 (152.4mm)
    (B) Outer Diameter, Bottom 6.00 (152.4mm)
    (C) Inner Diameter 3.50 (88.9mm)
    (D) Inner Diameter, Bottom 2.63 (66.8mm)
    (E) Length 29.25 (742.95mm)
    (F) Thread NONE
  • Physical Data
    Handle 1
    Seal Material BUNA-N
    Type of Adhesive EPOXY
    Type of Endcap PLATED STEEL
    Center Tube PLATED STEEL
    Type of Media SS/TEFL/PAPER
    Filter Area 3750 SQ.IN.
    Plating ELECTROTIN PLATED
    Outer Jacket 0
    Configuration DOUBLE OPEN END
  • Packaging Data
    Number Per Carton 6
    Carton Weight 32.00lb (14.51 kg)
