MSC-K3100

Description: TURBINE OIL ELEMENT SEPARATOR

Specifications:
  • Performance Data
    Micron Rating: 4.20
    Beta Rating 1000
    Collapse Pressure Rating 100 PSID
    Maximum Temperature 250 F
    Direction of Flow
    Recommended Changeout Differential Pressure 15
  • Dimensional Data
    (A) Outer Diameter, Top 6.00 (152.4mm)
    (B) Outer Diameter, Bottom 6.00 (152.4mm)
    (C) Inner Diameter 3.50 (88.9mm)
    (D) Inner Diameter, Bottom 2.63 (66.8mm)
    (E) Length 29.00 (736.6mm)
    (F) Thread NONE
  • Physical Data
    Handle 1
    Seal Material BUNA-N
    Type of Adhesive EPOXY
    Type of Endcap PLATED STEEL
    Center Tube PLATED STEEL
    Type of Media SS/TEFL/GLASS
    Filter Area 3750 SQ.IN.
    Plating ELECTROTIN PLATED
    Outer Jacket 0
    Configuration DOUBLE OPEN END
  • Packaging Data
    Number Per Carton 6
    Carton Weight 40.00lb (18.14 kg)
